Intra Oral Sensor DIOR
General Specification
| Model | DIOR Crystal |
| Part No | 904-000032-01 |
| Description | Intra Oral Sensor for Dental X-Ray |
Computer Hardware Requirements
| Operating System | Windows 8.0 or higher |
| Processor | Intel 13 or Better |
| Ram | 4GB |
| Usb | 2.0 High Speed |
| Monitor | 17" or Better |
| Language | English |
Sensor Specifications
| Image area | Size 1 (20mm x 30mm) |
| Chip/Sensor | 14-Bit CMOS |
| Scintillato | Cesium Iodide (Csl) |
| Light Guide | Fibre Optic Plate |
| Pixel Size | 200 x 200 |
| Pixel Resolution | 1500 x 1000 |
| Dimensions | 39mm x 25mm x 5.3mm (thick) |
| Connection | USB 2.0 wired |
| Image Resolution | 20 line pairs per mm |
| Casing | Waterproof ip67 |
